Esoteric F-07 Integrated Audio Amplifier

MSRP: €8000,00
€7500,00
(You save €500,00 )
(4 reviews) Write a Review
SKU:
156580
UPC:
4907034220854
Availability:
After receiving the order, we will update you on estimated time of delivery.
Shipping:
Free Shipping
Power output:
2x100W @8Ω (2x170W @4Ω)
Construction:
Discrete Dual Monaural, Balanced preamp, Bipolar power amp
Adding to cart… The item has been added

Basic and Complete

Striving for an all-encompassing sense of presence unmatched in its category, the F-07 Integrated Amplifier omits none of the remarkable performance features found in Esoteric's flagship Grandioso separate amps. Richly capturing the full warmth and texture of music, all of the superb powers of expression and audio performance for which the Grandioso line has won renown are now condensed into an integrated form offering exceptional ease of use and broad appeal that more than compensates for its compact proportions.

F-07

F-Series Philosophy: Basic and Complete



  • Full Analogue
    Analog amplification circuitry inherited from Esoteric's flagship Grandioso series for consistently superb sound quality.
  • Fully Integrated
    Aspiring to be superior examples of the integrated amplifier format.
  • Fundamental
    Invested with the finest materials and expertise in pursuit of the essence of amplifier design, while seeking uncommon sophistication and substance in the most basic format.
  • Functional
    Offering more versatile tone control capability than separates, while bringing out the full potential of the integrated amplifier by providing ample functionality and abundant expandability in its overall refinement.

F-07

Audio expression, symphonic beauty, artistic passion, the concert hall's spatial feel, the excitement of the audience. Esoteric's Master Sound Works is an audio product concept that recreates all of the music information in original master recordings with the most state-of-the-art technology available today.

A Fully Balanced Preamplifier

F-07

Virtually impervious to noise, the preamplifier's fully balanced configuration delivers pure and powerful signal amplification at ultra-low impedance. 。

Dual Monaural by Design

Most clearly reflecting Grandioso thinking, the F-07's dual monaural configuration maintains complete left and right channel independence through all stages, from the preamplifier to the power amplifier's final stage. Outstanding circuit construction also yields excellent channel separation and sound quality to transcend the class.

ESOTERIC-QVCS

Playing a significant role in the F-07's balanced dual monaural configuration is Esoteric's proprietary Quad Volume Control System (QVCS), which incorporates a total of four precision switched resistor ladder networks operating in unison to independently and electronically control the left and right channels and their positive and negative phases. This system helps maintain superb audio clarity, excellent channel separation and highly accurate phase characteristics. Further, by eliminating all volume control wiring on the audio board, the resulting shorter signal path minimizes deterioration of sound quality while realizing exceptionally low distortion.

Ultra-Low-Noise Logic Control

As a countermeasure against noise, control board is housed in the front panel and electronically isolated from the main preamplifier board.

High-Precision Ball Bearing Control Knobs

F-07

Employing the same high-precision bearing mechanisms used in our Grandioso components, the F-07's volume control knob and selector switches offer exceptionally smooth operation with an analog feel free of mechanical play. Sparing no cost, all panel knobs have also been custom-machined from solid aluminum.

Dual Mono Phonostage Preamp

The dual mono phono equalizer (MM/MC) features independent left and right channel power supplies and independent circuits.

High-Quality Headphone Amplifier

The F-07's powerful headphone amp delivers ample output to effectively drive high-impedance headphones.

2-Band (Treble/Bass) Tone Control

F-07

Consisting of four circuits (L/R, –/+) for each band, the system's balanced dual monaural configuration enables the user to adjust tone settings free of any concerns about deterioration of sound quality. Shifting the variable bands more toward the high and low frequency ranges (14kHz/63Hz) permits fine tone adjustment without adversely affecting the original source signal. Fully electronic control also permits fine adjustment of up to ±12dB in 0.5dB steps.

Balanced Power Amplifier Input Stage

F-07

With its balanced front stage, the power amplification section's clean amplification and low impedance further enhance the dynamic range.

Large-Capacity Custom Power Transformer - The Nucleus of the Finest Power Amplifiers

F-07

The power supply features a large-core 633VA custom EI power transformer and 40,000µF block capacitors for each channel in its dual monaural configuration. Large-gauge cable used in all power connections helps minimize impedance to further ensure that every musical dynamic is faithfully reproduced by this outstanding power section.

Low Impedance Output Stage Design

The speaker output section employs eight 1mm-thick high-purity OFC bus bars and MOSFET switching with no mechanical contacts. Coils have also been eliminated from the output stage to minimize impedance and enhance drive capability.

Powerful Bipolar Transistors Deliver 30 Amperes of Instantaneous Peak Output

F-07

Large bipolar transistors deliver an outstanding continuous current capacity of 15A, and 30A of instantaneous peak power to ensure accurate reproduction of the most delicate tones.

3-Stage Darlington Circuit with 2 Parallel Push-Pull Configuration + LIDSC

F-07

The F-07's amplifier modules inherit the true spirit of our flagship Grandioso line with a three-stage Darlington configuration that utilizes two parallel push-pull sections. Proprietary LIDSC* circuitry reduces the drive section's second stage to final stage output impedance, achieving loudspeaker drive capability closely rivals to that of our separate amplifiers.
* LIDSC: Low Impedance Drive Stage Coupling

3D Optimized Chassis Construction

F-07

The F-07's robust 3D Optimized Chassis construction gives each circuit block its own dedicated compartment. Interference between circuits is effectively minimized while achieving the shortest possible cable routing. Chassis exteriors are formed of thick aluminum panels manufactured with the same uncompromising design philosophy imbued in Esoteric's separate amplifiers. As a result, their heavy-duty construction tips the scales at a total weight of 27.2kg, exceptional among integrated models. The steel insulators supporting the unit at four points further exemplify the rigorous countermeasures taken to minimize the effects of vibration.

F-07F-07

Designed for System Upgrades

F-07

The preamplifier and power amplifier sections of the F Series boast the same degree of refinement as Esoteric's separates, and can both be used as standalone devices, or even disabled if not in use. The PRE-out employs a powerful buffer amplifier. System upgrades can also be performed with no compromises in quality, and an optional board slot facilitates the installation of an optional board, such as OP-DAC1 D/A Converter Board or OP-ESLA1 ES-Link Analog Input Board.

Other features

  • Organic EL display (Normal / Large font).
  • Two speaker terminal systems (A / B / A+B).
  • Independently adjustable input gains (±18dB; 0.5dB steps).
  • L/R channel balance.
  • Individually selectable phase inversion for each source.
  • AV through output (volume bypass) ensures seamless coexistence with AV systems.
  • RCA preamp output jack can be switched between PRE Out and REC Out.
  • Aluminum body remote controller can also be used to operate Esoteric's SACD players.
  • Displayed source device names can be programed.

Spec description

Speaker output
Rated output 100W + 100W (8Ω)
170W + 170W (4Ω)
Minimum compatible impedance
Damping factor 370
Speaker terminals Screw type × 2 sets (L/R)
Analog audio inputs
XLR (LINE) 1 pair
Input impedance 10kΩ
RCA (LINE) 4 pairs
Input impedance 10kΩ
RCA (PHONO) 1 pair
Input impedance
MC 100Ω
MM 47Ω
XLR (Pre-in) 1 pair
Input impedance 47Ω
Analog audio outputs
RCA (Pre-out) 1 pair
Output impendace 100Ω
Pre-out S/N ratio
XLR, RCA IN 109dB (1V output)
PHONO MC IN 75dB (1V output)
PHONO MM IN 93dB (1V output)
General
Power supply
  AC 230V, 50Hz
  AC 120V, 60Hz
  AC 220V, 60Hz
External dimensions (W×H×D) 445 × 191 × 468mm
17-⅝" × 7-⅝" × 18-½" (including protrusions)
Weight 27.2kg / 60 lb
Included accessories Power cord × 1
Remote cotrol (RC-1301) × 1
AAA batteries × 2
Felt pads × 4
Owner's manual × 1
Warranty card × 1



Audio performance

Frequency 10Hz to 100kHz (0dB/–3dB, 1W output)
S/N ratio 110dB (IHF-A)
Total harmonic distortion 0.008% (100W)
Gain
Preamplifier 24.5dB (when VOLUME at maximum)
Power amplifier 29dB
Tone controls
Bass ±12dB (63Hz)
Treble ±12dB (14kHz)



Tone control curves

F-07

Bass

  F-07

Treble





  • This product is available in two different power supply variations, as shown in the chart above. Make sure that the voltage shown on the rear panel matches the AC line voltage in your area.
  • The shape of the AC inlet and plug of the supplied power cord depends on the voltage rating and destination country.
  • Design and specification are subject to change without notice.
  • Weight and dimensions are approximate.



View product brochure.

Download english/french/spanish user manual.

Download german/italian user manual.

2 years
